SHUTTLE Barebone Sh510R4 - S1200,

Forsiden Datamaskiner Arbeidsstasjoner SHUTTLE Barebone Sh510R4 - S1200,
SHUTTLE Barebone Sh510R4 - S1200, (SH510R4)
SHUTTLE Barebone Sh510R4 - S1200, (SH510R4)
SHUTTLE Barebone Sh510R4 - S1200, (SH510R4)
SHUTTLE Barebone Sh510R4 - S1200, (SH510R4)
SHUTTLE Barebone Sh510R4 - S1200, (SH510R4)
SHUTTLE Barebone Sh510R4 - S1200, (SH510R4)
SHUTTLE Barebone Sh510R4 - S1200, (SH510R4)
SHUTTLE Barebone Sh510R4 - S1200, (SH510R4)
SHUTTLE Barebone Sh510R4 - S1200, (SH510R4)
SHUTTLE Barebone Sh510R4 - S1200, (SH510R4)
SHUTTLE Barebone Sh510R4 - S1200, (SH510R4)
SHUTTLE Barebone Sh510R4 - S1200, (SH510R4)
SHUTTLE Barebone Sh510R4 - S1200, (SH510R4)
SHUTTLE Barebone Sh510R4 - S1200, (SH510R4)
SHUTTLE Barebone Sh510R4 - S1200, (SH510R4)
SHUTTLE Barebone Sh510R4 - S1200, (SH510R4)
SHUTTLE Barebone Sh510R4 - S1200, (SH510R4)
SHUTTLE Barebone Sh510R4 - S1200, (SH510R4)
SHUTTLE Barebone Sh510R4 - S1200, (SH510R4)
SHUTTLE Barebone Sh510R4 - S1200, (SH510R4)
SHUTTLE Barebone Sh510R4 - S1200, (SH510R4)
SHUTTLE Barebone Sh510R4 - S1200, (SH510R4)
SHUTTLE Barebone Sh510R4 - S1200, (SH510R4)
SHUTTLE Barebone Sh510R4 - S1200, (SH510R4)

SHUTTLE Barebone Sh510R4 - S1200,

Varenr.:
SH510R4
EAN:
0887993003948
  • Formfaktor Mikro-tårn
  • Prosessor Ingen CPU
  • Antall prosessorer 0
  • Diskret grafikk Ikke tilgjengelig
  • HDD 0GB
  • SSD / Flash 0GB
  • Minne 0GB
  • Operativsystem Fri-DOS (operativsystem)
  • Modell Shuttle XPC Cube
  • CTO / BTO Nei
3 178,-
3 972,50 inkl. mva
LEASING (ekskl. mva)
6-mnd
159,-/mnd
12-mnd
318,-/mnd
Ved Leasing gjelder: Etableringsgebyr 0,-, faktureringsgebyr 0,-/mnd, minimumsordre 0,-. Frakt og mva. kommer i tillegg. Forutsetter kredittgodkjenning. Leasing kan velges som en betalingsmåte når du går til kassen.
Beskrivelse

XPC cube SH510R4


Entry-level platform for Intel's 10th/11th Gen. processors

The Shuttle XPC cube Barebone SH510R4 supports the 10th and 11th generation of Intel Core desktop processors for socket LGA1200, up to 64 GB DDR4-3200 memory, two 4K displays at 60 Hz via DisplayPort and HDMI 2.0, high-performance M.2 SSDs and up to four USB 3.2 devices. The SH510R4 can be expanded with a high-performance graphics card for demanding applications while the second PCIe-X1-slot can be used for other expansion cards. WLAN and COM port can be additionally installed as well. The SH510R4 comes with a built-in 80 PLUS power supply and Shuttle's I.C.E. heatpipe cooling which means it is energy-efficient and ready for long-term operation. For a personal look and feel, the front panel can be customised by adding individual designs.


Features:

  • For Intel processors in the LGA1200 socket (Gen 10/11)
  • Up to 64 GB of DDR4 memory
  • Two M.2 slots (1× M.2-2280, 1× M.2-2230)
  • PCIe-×16-4.0 for dual-slot graphics cards
  • PCIe-×1-3.0 for expansion cards
  • 4× USB 3.2 (5 Gbit), 4× USB 2.0
  • 1× HDMI 2.0b, 1× DisplayPort 1.4, 1× VGA
  • 3× SATA and space for 2× 3.5" and 1× 5.25" drives
  • Customisable front panel design
  • Remote power-on connection

Specifications:

Chassis
  • Black aluminium chassis with acrylic front plate
  • Customisable front panel design: simply change the mylar and add a personal design
  • such as a photo, graphics or a logo to the front panel.
  • Storage bays: 1 x 5.25" (external), 2 x 3.5" (internal)
  • Dimensions: 32.9 x 21,6 x 19.0 cm (LWH without feet) = 13.4 litres
  • Height with rubber feet: 19.7 cm
  • Weight: 3.4 kg net / 4.5 kg gross
Mainboard / Chipset
  • Mainboard with Shuttle form factor, proprietary design for XPC SH510R4
  • Chipset/Southbridge: Intel® H510
  • Passive chipset cooling with heat sink
  • The Northbridge is integrated in the processor.
  • Solid Capacitors for sensitive areas provide excellent heat resistance for enhanced system durability
BIOS
  • AMI BIOS, SPI Interface, 16 MB Flash-EEPROM
  • Supports Hardware Monitoring, Watch Dog
  • Supports Power Fail Resume
  • Supports Firmware-TPM (fTPM) v2.0
  • Supports boot up from external USB flash memory
  • Supports Unified Extensible Firmware Interface (UEFI)
Power supply
  • Built-in 300 Watt mini switching power supply
  • AC input voltage: 100~240V, 50~60 Hz
  • 80 PLUS Bronze compliant: The PSU provides at least
  • 82/85/82% of efficiency at 20/50/100% of load.
  • Active PFC circuit (Power Factor Correction)
  • ATX main power connectors: 2x10 and 2x2-pin
  • Graphics power connector: 6-pin
  • Other connectors: 4x SATA, 2x Molex
Operating System
  • This system comes without operating system.
  • It is compatible with Windows 10/11 (64-bit) and Linux (64-bit)
Processor support
  • Processor Socket LGA 1200
  • Supports Intel Core i9 / i7 / i5 / i3, Pentium Gold and Celeron processors
  • Supports the 10th and 11th generation Intel Core processors, code name "Comet Lake-S" and "Rocket Lake-S" in 14++ nm process technology
  • Maximum supported processor power consumption (TDP) = 125 W
  • Up to 10 CPU cores, 20 threads and 20 MB of L3 cache
  • Does not support the unlock-function of Intel K-Series processors.
  • The processor integrates PCI-Express, memory controller and the graphics engine on the same die.
  • However, processors with "F" identifier do not support integrated graphics
    (performance features depending on processor type)
Heat-pipe processor cooling
  • Shuttle I.C.E. (Integrated Cooling Engine) advanced I.C.E. heatpipe technology, linear-controlled 92mm fan
  • SilentX cooling and noise reduction technology with Active Airflow
Memory support
  • 2x 288-pin slot
  • Supports DDR4 memory at 1.2V
  • Supports Dual Channel mode
  • Supports max. 32 GB per DIMM, maximum total size of 64 GB
  • The maximum DDR4 clock frequency depends on the processor type used:
    • Gen. 11 "Rocket Lake" supports DDR4-3200 (PC4-25600U)
    • Gen. 10 "Comet Lake" Core i7/i9 supports DDR4-2933 (PC4-23433U)
    • other "Comet Lake" support DDR4-2666 (PC4-21300U)
PCIe Expansion Slots
  • 1x PCI-Express x16 v4.0 slot
    (supports PCI-Express v3.0 with Gen. 10 "Comet Lake" processors)
  • 1x PCI-Express x1 v3.0 slot, open-ended
  • Supports dual-slot (double-width) graphics cards (occupies the second PCI-Express slot)
  • The maximum size acceptable for display cards is 273 x 98 x 38 mm.
  • Graphics power connector: 6 pins
Integrated Graphics (optional)
  • The features of the integrated Intel UHD graphics function depend on the processor type used.
  • Certain processor models do not support integrated graphics
  • The PC features three video outputs:
    • 1x HDMI v2.0b (only HDMI v1.4b with Gen. 10 "Comet Lake" Prozessoren)
    • 1x DisplayPort v1.4
    • 1x D-Sub/VGA
  • HDMI 2.0b and DisplayPort support displays with 4K Ultra HD resolution at 3840 x 2160 at 60 Hz refresh rate (2160p/60)
  • HDMI 1.4b supports Ultra HD resolution at 30 Hz.
  • Supports two independent displays with the integrated graphics function
  • Supports more displays in combination with a discrete graphics card
  • Hardware video decoding/encoding
  • DisplayPort and HDMI support multi-channel digital audio over the same cable
Drive bays
  • Storage bays: 1 x 5.25" (external), 2 x 3.5" (internal)
  • Using the optional accessory PHD3
  • two 2.5" drives can be installed into one 3.5" bay.
SATA connectors
  • 3x Serial ATA 6G connector onboard (rev. 3.0, max. 6 Gbit/s)
M.2-2280M SSD slot
  • The M.2 2280M slot provides the following interfaces:
    • PCI-Express Gen. 3.0 X4, supports NVMe
    • SATA v3.0 (max. 6 Gbps)
  • It supports M.2 cards with a width of 22 mm
  • and a length of 42, 60 or 80 mm (type 2242, 2260, 2280).
  • Supports M.2 SSDs with SATA or PCI-Express interface
M.2-2230E slot for WLAN cards
  • Interfaces: PCI-Express Gen. 3.0 X1 und USB 2.0
  • Supports M.2 cards with a width of 22 mm and a length of 30 mm (type 2230)
  • Supports WLAN extension cards (optional Shuttle accessory: WLN-M)
HD audio
  • Audio Codec: Realtek ALC662/ALC897/ALC888S, 5.1 channel
  • Three analog audio connectors (3.5mm) at the backpanel:
  • Line-in (blue), line-out (green) and microphone input (pink)
  • shared with 5.1 channel line-out (front, rear, center/bass)
  • Front panel: microphone input and head-phones output (line-out)
  • DisplayPort and HDMI support multi-channel digital audio over the same cable
Gigabit LAN
  • Intel i219LM PHY connected to the MAC of the processor
  • Supports 10 / 100 / 1.000 MBit/s operation
  • Supports WAKE ON LAN (WOL)
  • Supports network boot by Preboot eXecution Environment (PXE)
Front Panel connectors and buttons
  • Microphone input (3.5 mm)
  • Headphone output (3.5 mm)
  • 2x USB 3.2 Gen 1 (max. 5 Gbps), blue
  • Power button
  • Power indicator (Blue LED)
  • Hard disk drive indicator (Yellow LED)
Back Panel connectors
  • 1x HDMI 2.0b (HDMI 1.4b with Gen. 10 "Comet Lake" processor)
  • 1x DisplayPort 1.4
  • 1x D-Sub VGA (analog)
  • 2x USB 3.2 Gen 1 (max. 5 Gbps), blue
  • 4x USB 2.0 (black)
  • 1x Gigabit LAN (RJ45)
  • 1x Audio Line-out (3.5 mm)
  • 1x Audio Line-in (3.5 mm)
  • 1x Microphone Input (3.5 mm)
  • 1x 4-pin connector (2.54 mm pitch) supports:
    • external power on button
    • Clear CMOS function
    • 5V DC voltage for external components
  • Optional: Serial RS232 port (Accessory: "H-RS232")
  • 3x perforation for optional WLAN antennas (Accessory: "WLN-M")
Other connectors
  • Occupied front panel connectors for USB, audio, buttons, LEDs
  • 1x RS232 serial interface (2x5 pin header)
  • 2x fan connectors (4-pin header)
  • 1x USB 2.0 (4-pin header)
Included Accessories
  • Multi-language XPC Installation Guide (EN, DE, FR, ES, JP, KR, SC, TC)
  • Windows 64-bit driver disk
  • 2x Serial ATA cables
  • AC Power Cord (with protective-earth contacts)
  • Heatsink Compound
  • Protector cap for the CPU socket (do not use if heatpipe or fan is mounted)
  • Bag with screws
Optional Accessories
  • Back panel adapter for serial RS232 port (H-RS232)
  • WLAN IEEE 802.11ac/BT4.2 kit with two external antennas (WLN-M)
  • Adapter for 2.5" drives such as SSDs (PHD3)
  • Adapter cable for external power button (CXP01)
Environmental criteria
  • Permissible ambient temperature during operation: 0~40 °C
  • Relative humidity: 10~90 %.
Certifications / Compliance:
  • EMI: FCC, CE, BSMI, C-Tick
  • Safety: CB 60950/62368, cTUVus, BSMI
  • Other: RoHS, Energy Star 5.0, ErP
  • This device is classed as a technical information equipment (ITE) in class B and is intended for use in living room and office. The CE-mark approves the conformity by the EU directives:
    • (1) 2014/30/EU relating to electromagnetic compatibility (EMC),
    • (2) 2014/35/EU relating to Electrical Equipment designed for use within certain voltage limits (LVD),
    • (3) 2009/125/EC relating to ecodesign requirements for energy-related products (ErP).
